Borroughs-bulkrivetshelving

Borroughs Bulk Rivet Shelving
Shelving - Bins - Shelves - Borroughs - Rivet Span - Storage Systems
Borroughs Industrial Shelving systems are the back bone of the material handling industry. Within the shelving industry there are three different classifications of shelves which
are similar in function but different in design. Rivet rack and standard shelving are the most commonly referred to products when storage systems are mentioned.

Borroughs - Rivetspan is inexpensive storage for bulky loads
Frame work snaps together quickly and easily!!
Premium quality at affordable Prices!
$.10/lb Steel Surcharge included - 8/ 01/17

Rivet-Span bulk storage units are ideally suited to virtually any type of hand-loaded material. It is designed for greater cube capacity than standard shelving, but lower priced than pallet rack. Rivet-Span can be used for storing a broad range of bulky parts or hard-to-store items. Back to Shelving Page				Borroughs Rivetspan
48" Wide Units specify starter or adder units				Standard Height: 84" high unit - 7'-0" high standard Other heights available upon request
Size	Capacity per shelf	4 shelf unit	Wt ea	Price ea	Additional Level	Wt ea	Price ea
48" x 18"	730#	B4818DR47	59.2	79.15	BL4818DR	9.0	13.36
48" x 24"	730#	B4824DR47	62.4	82.40	BL4824DR	11.0	14.33
48" x 36"	730#	B4836DR47	68.8	86.55	BL4836DR	13.0	16.55
48" x 48"	730#	B4848DR47	76.0	99.47	BL4848DR	15.0	18.74
60" Wide Units specify starter or adder units				Standard Height: 84" high unit - 7'-0" high standard Other heights available upon request
Size	Capacity per shelf	4 shelf unit	Wt ea	Price ea	Additional Level	Wt ea	Price ea
60" x 18"	1,300	B6018DH47	72.4	98.72	BL6018DH	11.0	18.10
60" x 24"	1,300	B6024DH47	77.6	103.80	BL6024DH	13.0	19.45
60" x 36"	1,300	B6036DH47	88.0	116.00	BL6036DH	15.0	22.45
60" x 48"	1,300	B6948DH47	99.2	128.80	BL6048DH	17.0	25.53
72" Wide Units specify starter or adder units				Standard Height: 84" high unit - 7'-0" high standard Other heights available upon request
Size	Capacity per shelf	4 shelf unit	Wt ea	Price ea	Additional Level	Wt ea	Price ea
72" x 18"	1,050	B7218DH47	79.6	106.80	BL7218DH	13.0	20.14
72" x 18"	1,700	B7218CH47	109.2	122.47	BL7218CH	13.0	24.14
72" x 24"	1,050	B7224DH47	84.8	111.90	BL7224DH	15.0	21.50
72" x 24"	1,700	B7224CH47	114.4	126.52	BL7224CH	15.0	25.49
72" x 36"	1,050	B7236DH47	95.2	124.12	BL7236DH	17.0	24.48
72" x 36"	1,700	B7236CH47	117.4	138.87	BL7236CH	17.0	28.48
72" x 48"	1,050	B7248DH47	106.4	136.90	BL7248DH	19.0	27.58
72" x 48"	1,700	B7248CH47	128.8	151.67	BL7248CH	19.0	31.57
96" Wide Units specify starter or adder units				Standard Height: 84" high unit - 7'-0" high standard Other heights available upon request
Size	Capacity per shelf	4 shelf unit	Wt ea	Price ea	Additional Level	Wt ea	Price ea
96" x 18"	650	B9618DH47	100.0	135.35	BL9618DH	19.2	27.41
96" x 18"	1,300	B9618CH47	130.0	154.24	BL9618CH	25.0	33.20
96" x 24"	650	B9624DH47	107.7	142.32	BL9624DH	20.0	29.02
96" x 24"	1,300	B9624CH47	137.2	161.14	BL9624CH	25.8	34.80
96" x 36"	650	B9636DH47	121.6	158.05	BL9636DH	21.6	35.08
96" x 36"	1,300	B9636CH47	151.6	176.95	BL9636CH	27.2	38.47
96" x 48"	650	B9649DH47	136.8	175.22	BL9648DH	23.6	36.78
96" x 48"	1,300	B9648CH47	166.8	194.10	BL9648CH	29.2	42.53
Wood Decking 5/8" particle Board				Prices are per each piece Prices may vary for Quantity
48" Decking				72" Decking
48" x 18"		Call for Pricing		72" x 18"	Call for Pricing
48" x 24"				72" x 24"
48" x 36"				72" x 36"
48" x 48"				72" x 48"
60" Decking				96" Decking
60" x 18"		Call for Pricing		96" x 18"	Call for Pricing
60" x 24"				96" x 24"
60" x 36"				96" x 36"
60" x 48"				96" x 48"

*Borroughs Rivet Span*
